제품 상세 정보:
|
| 패키지 크기: | 5.0x5.0x1.6mm | 칩 구성: | 단일 흰색/RGB 3-in-1/RGBW/주소 지정 가능 IC |
|---|---|---|---|
| 광속(백색): | 18-28lm @ 60mA | 시야각: | 120° |
| 순방향 전압(백색): | 3.0-3.4v | 순방향 전압(RGB): | R:2.0-2.2V, G:3.0-3.4V, B:3.0-3.4V |
| 순방향 전류: | 칩당 60mA | 색온도(백색): | 2700K / 3000K / 4000K / 5000K / 6500K |
| CRI: | ≥80(표준), ≥90(높은 CRI 옵션) | 수명(L70): | ≥50,000 시간 |
| 작동 온도: | -40°C ~ +85°C | ESD 보호: | 내장(RGB 변형) |
| 용접 방법: | 리플로우 납땜, RoHS 준수 | ||
| 강조하다: | High Brightness 5050 SMD LED,RGB Multi Color LED Chip,LED Strip Lighting Component |
||
5050 SMD LED 5.0x5.0mm High Brightness RGB White Chip for LED Strip Architectural Commercial Lighting Product Overview The 5050 SMD LED is a premium surface-mount LED component housed in a 5.0 mm * 5.0 mm package, delivering 18–28 lumens of luminous flux with a wide 120° viewing angle. Its larger form factor compared to 3528 and 2835 packages enables superior thermal management and higher drive currents (up to 60 mA per chip), making it the industry-standard choice for high
